Forged 45 Deg Screwed-Threaded Elbow
Forged 45 Deg Screwed-Threaded Elbow Manufacturers & suppliers in India
Stainless Steel Forged 45 Deg Screwed-Threaded Elbow Suppliers, ASME B16.5/ B16.9/ B16.11/ B16.36/ B16.25/ B16.49 Stainless Fittings, ASTM A182 Forged 45 Deg Screwed-Threaded Elbow, threaded pipe fittings & socket weld pipe fittings manufacturers
High pressure pipe fittings & forged steel fittings, Forged 45 Deg Screwed-Threaded Elbow Stockholders
Welded / Seamless, 45° | 45°, Long Radius (LR) | Short Radius (SR) manufacturing in Our Work Shop
Hathway / Dynamic was the first company in India who was awarded the order to Supply Stainless Steel Forged Fittings & Forged 45 Deg Screwed-Threaded Elbow by Indian Oil Corporation for their refinery at Mundra. In 2008 Jordan Petroleum Refinery Company Limited selected Hathway Metals to supply stainless steel butt weld fittings & alloy steel forged fittings to Amman, Jordan out of 6 top manufacturers of forged fittings in INDIA based on pressure rating of our forged fittings.
Hathway / Dynamic is an approved manufacturer of high nickel based special alloy buttweld pipe fittings and Forged 45 Deg Screwed-Threaded Elbow, ss socket weld fittings, stainless pipe fittings, seam welded 100% radiography tested pipe fittings to requirements of BVIS, IBR, BARC, DNV, BHEL & we are ISO 4501:2008, 14001:2004, OHSAS 18001:2007 certified company.
Type of Butt weld Stub Ends | Lap Joint :
- Forged 45 Deg Screwed-Threaded Elbow Material, Size & Specification
- Forged 45 Deg Screwed-Threaded Elbow Dimensions
- Forged 45 Deg Screwed-Threaded Elbow Project Reference List
- Dealer & Distributor of World’s Top 10 Manufacturers of Forged 45 Deg Screwed-Threaded Elbow
- Forged 45 Deg Screwed-Threaded Elbow Latest Price »
- 1/8? Socket Weld Elbow 304/304L, 3000 LB
- FOB Price: $10.57
Forged 45 Deg Screwed-Threaded Elbow Material, Size & Specification
| Specification |
|
|---|---|
| Forged 45 Deg Screwed-Threaded Elbow Dimension | ANSI B 16.11 |
| Forged 45 Deg Screwed-Threaded Elbow Size | 1/4″ NB TO 4″ NB |
| Forged 45 Deg Screwed-Threaded Elbow Class | 2000 LBS, 3000 LBS, 6000 LBS, 4500 LBS |
| Forged steel fittings Range | Coupling, Plug, Socket, Bushing, Elbow, Tee, Nipple, Union,Threading Outlet, Welding Outlet, Sockt Weld Outlet. |
| Stainless Steel Forged 45 Deg Screwed-Threaded Elbow | ASTM A182 F304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 454L |
| Duplex Steel Forged 45 Deg Screwed-Threaded Elbow | ASTM A 182 –F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61 S 31803, S 32205, S 32550, S 32750, S 32760 |
| Carbon Steel Forged 45 Deg Screwed-Threaded Elbow | ASTM/ ASME A 105, ASTM/ ASME A 350 LF 2 |
| Alloy Steel Forged 45 Deg Screwed-Threaded Elbow | ASTM / ASME A 182 GR F5, F 9, F 11, F 12, F 22, F 91. |
| Copper Alloys Forged 45 Deg Screwed-Threaded Elbow | ASTM / ASME SB 111 UNS NO. C 10100 , C 10200 , C 10300 , C 10800 , C 12000, C 12200, C 70600 C 71500 ASTM / ASME SB 466 UNS NO. C 70600 (CU -NI- 45/10) , C 71500 (CU -NI- 70/30) |
| Nickel Alloy Forged 45 Deg Screwed-Threaded Elbow | ASTM / ASME SB 336, ASTM / ASME SB 564 / 160 / 163 / 472, UNS 2200 (NICKEL 200) , UNS 2201 (NICKEL 201), UNS 4400 (MONEL 400), UNS 8020 (ALLOY 20 / 20 CB 3), UNS 8825 INCONEL (825) , UNS 6600 (INCONEL 600), UNS 6601 (INCONEL 601) , UNS 6625 (INCONEL 625) , UNS 10276 (HASTELLOY C 276) |
| Low temperature steel: | A522 A707 Grade L 1-L 2-L 3-L 4-L 5-L 6-L 7-L 8 |
| High performance steel: | A694 F 42-F 46-F 48-F 50-F 52-F 56-F 60-F 65-F 70 |
Forged 45 Deg Screwed-Threaded Elbow Dimensions
| Class 2000 |
Nominal Pipe Size |
1/8 | 1/4 | 3/8 | 1/2 | 3/4 | 1 | 1 1/4 | 1 1/2 | 2 | 2 1/2 | 3 | 4 |
| A | – | 7/8 | 31/32 | 1 1/8 | 1 5/16 | 1 1/2 | 1 3/4 | 2 | 2 3/8 | 3 | 3 3/8 | 4 3/16 | |
| B | – | 29/32 | 1 1/16 | 1 5/16 | 1 9/16 | 1 27/32 | 2 7/32 | 2 1/2 | 3 1/32 | 3 11/16 | 4 5/16 | 5 3/4 | |
| Wt | – | 0.198 | 0.283 | 0.500 | 0.773 | 1.013 | 1.550 | 2.180 | 3.140 | 6.500 | 10.925 | 26.675 | |
| Class 3000 | 1/8 | 1/4 | 3/8 | 1/2 | 3/4 | 1 | 1 1/4 | 1 1/2 | 2 | 2 1/2 | 3 | 4 | |
| A | 7/8 | 31/32 | 1 1/8 | 1 5/16 | 1 1/2 | 1 3/4 | 2 | 2 3/8 | 2 1/2 | 3 1/4 | 3 3/4 | 4 1/2 | |
| B | 29/32 | 1 1/16 | 1 5/16 | 1 9/16 | 1 27/32 | 2 7/32 | 2 1/2 | 3 1/32 | 3 11/32 | 4 | 4 3/4 | 6 | |
| Wt | 0.236 | 0.350 | 0.592 | 0.973 | 1.355 | 2.265 | 2.407 | 3.500 | 5.920 | 11.450 | 14.438 | 31.975 | |
| Class 6000 | 1/8 | 1/4 | 3/8 | 1/2 | 3/4 | 1 | 1 1/4 | 1 1/2 | 2 | 2 1/2 | 3 | 4 | |
| A | 31/32 | 1 1/8 | 1 5/16 | 1 1/2 | 1 3/4 | 2 | 2 3/8 | 2 1/2 | 3 1/4 | 3 3/4 | 4 3/16 | 4 1/2 | |
| B | 1 1/6 | 1 5/16 | 1 9/16 | 1 27/32 | 2 7/32 | 2 1/2 | 3 1/32 | 3 11/32 | 4 | 4 3/4 | 5 3/4 | 6 | |
| Wt | 0.250 | 0.625 | 1.023 | 1.625 | 2.625 | 3.500 | 6.750 | 7.500 | 13.438 | 20.875 | 39.050 | 38.000 | |
45° ELBOWS – THREADED – B16.11
Forged 45 Deg Screwed-Threaded Elbow Project Reference List
(Updated projects list from 2015 onwards, please contact our Sales Office)
Hathway / Dynamic supplied Forged Pipe Fittings in more then 37 countries in last 10 years
| PROJECT NAME / CUSTOMER | HATHWAY SUPPLIED | GRADES | LOCATION | YEAR |
|---|---|---|---|---|
| INDORAMA | Forged 45 Deg Screwed-Threaded Elbow AND BRANCH OUTLETS BW – SW – THRD | A105 – A350 LF2 – A106B- A333 GR6 – A234 WPB – A420 WPL6 – A182 F304L | THE NETHERLANDS | 2015 |
| GAS AND CONDENSATE EXPORT SYSTEM | Forged 45 Deg Screwed-Threaded Elbow AND BRANCH OUTLETS BW – SW | A182 F316L – A182F44 A182 F44 , A312S31254, A182 F316L, A105.N, A105 HDG, A350 LF2, A106 Gr.B, A106 Gr.B HDG , A333 Gr.6, A234 WPB |
KUWAIT | 2015 |
| GAS DEVELOPMENT PROJECT | Forged 45 Deg Screwed-Threaded Elbow, BRANCH OUTLETS | INCOLOY 825 | INDONESIA | 2015 |
| QUALITY STAMP TRADING -SAUDI ARAMCO | Forged 45 Deg Screwed-Threaded Elbow , BRANCH OUTLETS SW | A105, A105 GALV, A350 LF2, A182F304L, A182F316L, A403 WP316L, A182F321, A182F44, A182F5, CU45/10 UNS C70610 |
SAUDI ARABIA | 2014-2015 |
| REFINERY OFF GAS PROJECT | FORGED FITTINGS, BRANCH OUTLETS BW-THRD, NIP OUTLETS | A105, A105 HDG A350 LF2, A182 F304/ 304L, A182F316/316L, A182F11, A105N, A106B, A234WPB, A333 |
BELGIUM | 2014-2015 |
| MA’ADEN WA’AD AL SHAMAL PHOSPHATE | FORGED FITTINGS AND BRANCH OUTLETS SW-BW | A350LF2, F304L, F316L, F454L, A182F60, ALLOY20 A105N, A106B, A234WPB, |
SAUDI ARABIA | 2014-2015 |
| NORTH WEST REDWATER | FORGED FITTINGS SW & NPT | A350LF2,A420WPL6, A182F304L-F316L,WP304L,HAST,C276 |
CANADA | 2014-2015 |
| CANADA NWR PROJECT | FORGED FITTINGS , BRANCH OUTLETS SW & NPT | F304L/316L/317L/347H/321H F11/F22/ UNS08825 |
CANADA | 2014-2015 |
| DENIZ 2 PROJECT | FORGED FITTINGS SW & NPT | A 105, A105 GALVA, A350LF2, A333 Gr6, A234WPB-A420WPL6, F304L, WP304L |
AZERBAIJAN | 2014 |
| ADMA OPCO ABU DHABI | FORGED FITTINGS, BRANCH OUTLETS BW-THRD, LATERAL, OUTLETS | A694 F52, A182F321, A182F316, A105.N, A312TP316L, A312 TP321, A182 F53 SUPER DUPLEX |
UAE | 2014 |
| SAUDI ARAMCO HOLLAND | FORGED FITTINGS | CuNi 4510 | SAUDI ARABIA | 2014 |
| MISSAN OIL Comp.PETROCHINA IRAQ | API COUPLINGS | L80 | IRAQ | 2014 |
| SAUDI ARAMCO | Forged 45 Deg Screwed-Threaded Elbow, BRANCH OUTLETS BW-SW-THRD | MONEL 400, A182 F5, A182F316L, A182F304L, A105 |
SAUDI ARABIA | 2014 |
| OIL AND GAS INC | Forged 45 Deg Screwed-Threaded Elbow AND BRANCH OUTLETS BW | UNS NO 6625 | BRAZIL | 2014 |
| SHIDDIRGANG PROJECT | Forged 45 Deg Screwed-Threaded Elbow, BRANCH OUTLETS BW-SW-THRD | BANGLADESH | 2014 | |
| SAUDI ARABIAN MINING COMPANY | FORGED FITTINGS AND BRANCH OUTLETS SW – BW | A105, A105 GALV, A350LF2A182F304L, A182F316L |
SAUDI ARABIA | 2014 |
| GAS TURBINE POWER PLANT PROJECT | FORGED FITTINGS AND BRANCH OUTLETS SW | A105, A182F316L | IRAQ | 2014 |
| GRUPO CUNADO | FORGED STEEL FITTINGS | A105,A182F304L, A182F316L,F321, | TURKEY | 2013-2014 |
| ALSTOM | FORGED STEEL FITTINGS AND BRANCH OUTLETS | A105, A182F304L, A182F316L |
MOROCCO, SOUTH AFRICA |
2010 |
